High throughput: dozens to hundreds
of samples can be processed at the same time without cross-contamination.
Low temperature concentration: avoid
sample loss, denaturation, activity decline, oxidation.
Less loss: no foam generated from
the samples, less loss and high yield rate.
Safety and simplicity: one-button operation, safe and
convenient, avoiding misoperation.
Feature
1. Refrigerated model,
support low temperature concentration, concentrator chamber temperature -10 ~
100 ºC, 0.1 ºC increment, effective protection of
heat-sensitive biological samples.
2. Modular design,
centrifugal chamber, vacuum pump, cold trap are independent body, can be freely
assembled.
3. 7-inch touch screen
display: equipment running status, programme group number, set and actual
speed, set and actual temperature, set time and running time.
4. One-key start
function, the whole process in one go, high degree of automation.
5. Built-in vacuum delay function, vacuuming after the
rotational speed reaches the preset value, effective protection of samples,
anti-splash.
6. Maintenance-free
induction motor, electromagnetic drive centrifugal system, low noise,
maintenance-free.
7. Quick-insertion rotor
design, can quickly replace different rotors, rotor one-piece moulding without
welding point.
8. Anti-chemical
corrosion centrifugal chamber is made of aluminium alloy, R angle arc design,
no dead angle, easy to clean.
9. Built-in 32 groups of
different procedures, according to different samples, any call. Sample chamber
five temperature control design, effective protection of sample safety.
10. Adopting electronic
pressure sensor, more accurate value display, automatic vacuum release, easy
and safe operation, with automatic switch function.
11. Highly transparent
tempered glass cover, easy to observe the evaporation. 11. Highly transparent
tempered glass cover, easy to observe the evaporation.
12. Rotation speed(r/min):
0~2000.
13. Compatible rotor
capacity: 184*1.5ml/2ml; 132*1.5/2ml; 72*5ml; 24*15ml; 12*50ml; 8*100ml;
4*250ml, 2*96-well plate.
14. Max Centrifugal Force:
590Xg.
15. Temperature
control precision: ±1℃.
16. Range of Timing: 0~99h59min.
17. Ultimate vacuum value: <10pa.
18. Noise Level at Max Speed: 60dB(a).
19. Input Power: 1200W.
20. Preheating Function: Yes.
21. Stroboscope:
optional, able to realise the observation of sample concentration without
stopping the machine.
22. Input Voltage: AC220V 50Hz/60Hz
10A
23. External Dimension（L*D*H): 550*560*240mm
24. Weight: 60KG
25. Cold trap: small volume, vertical
structure, overall structure size: 260 (W) x 500 (D) x 480 (H) mm.
26. Standard cold trap tank volume 3L,
standard cold trap temperature -65℃.
27. The cold trap adopts PLC control,
4.3-inch touch screen display, displaying the cold trap temperature, setup
time, total running time, defrosting time, and one-key start.
28. 304 stainless steel cold trap tank body
is formed in one piece, the coil in the tank, the outer ring of the coil to the
inside wall of the tank around the space left 20-30mm, easy for users to clean
up the cleaning.
29. The cold
trap has a key frost function, can be arbitrarily modified defrost time.
30. The cold trap has a liquid
discharge port, liquid discharge is convenient.
31.
Anti-chemical corrosion vacuum pump pumping speed: 120L/min.
